SPI NOR Flash
兼具高性能和高安全性，满足多样化应用设计需求。
兆易创新是率先研发并成功推出SPI NOR Flash的公司之一。兆易创新SPI NOR Flash可提供多达16种容量选择，覆盖512Kb到2Gb，可满足多种实时操作系统所需的不同存储空间；并且，拥有四种不同电压范围，分别为3V、1.8V、1.2V以及针对电池供电应用推出的1.65V~3.6V宽压供电的产品系列；同时，提供多达20种不同的封装选项，可满足客户不同应用领域对容量、电压以及封装形式的需求。
显示191种器件
清空
清空
| 型号 | 状态 | 电压 | 容量 | 温度(工业) | 频率(MHz) | 主要特性 | 主要封装 |
|---|---|---|---|---|---|---|---|
| GD55X02GE | MP | 3V | 2Gb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x8), 200(x8 DTR) |
ECC,DTR, H/W RESET,WP#, Secured OTP | TFBGA24 8x6mm (5x5 ball array) |
| GD55LX02GE | MP | 1.8V | 2Gb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x8), 200(x8 DTR) |
ECC,DTR, H/W RESET,WP#, Secured OTP | TFBGA24 8x6mm (5x5 ball array) |
| GD55X01GE | MP | 3V | 1Gb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x8), 200(x8 DTR) |
ECC,DTR, H/W RESET,WP#, Secured OTP |
SOP16 300mil, TFBGA24 8x6mm (5x5 ball array) |
| GD55LX01GE | MP | 1.8V | 1Gb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x8), 200(x8 DTR) |
ECC,DTR, H/W RESET,WP#, Secured OTP |
SOP16 300mil, TFBGA24 8x6mm (5x5 ball array) |
| GD25X512ME | MP | 3V | 512Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x8), 200(x8 DTR) |
ECC,DTR, H/W RESET,WP#, Secured OTP |
SOP16 300mil, TFBGA24 8x6mm (5x5 ball array) |
| GD55LX512WE | MP | 1.8V | 512Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x8), 200(x8 DTR) |
ECC,DTR, H/W RESET,WP#, Secured OTP, RWW |
SOP16 300mil, TFBGA24 8x6mm (5x5 ball array) |
| GD25LX512ME | MP | 1.8V | 512Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
200(x1 x8), 200(x8 DTR) |
ECC,DTR, H/W RESET,WP#, Secured OTP |
SOP16 300mil, TFBGA24 8x6mm (5x5 ball array), WLCSP (4x6 ball array) |
| GD25LX256E | MP | 1.8V | 256Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
200(x1 x8), 200(x8 DTR) |
ECC,DTR, H/W RESET,WP#, Secured OTP |
SOP16 300mil, TFBGA24 8x6mm (5x5 ball array), WLCSP (4x6 ball array) |
| GD25LX128J | MP | 1.8V | 128Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
200(x1 x8), 200(x8 DTR) |
ECC,DTR, H/W RESET,WP#, Secured OTP | TFBGA24 8x6mm (5x5 ball array) |
| GD25NX128J | UD | 1.8V VCC, 1.2V VIO | 128Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
200(x1 x8), 200(x8 DTR) |
ECC,DTR, H/W RESET,WP#, Secured OTP |
TFBGA24 8x6mm (5x5 ball array), WLCSP (4x6 ball array) |
| GD25LX64J | MP | 1.8V | 64Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
200(x1 x8), 200(x8 DTR) |
ECC,DTR, H/W RESET,WP#, Secured OTP | TFBGA24 8x6mm (5x5 ball array) |
| GD25NX64J | UD | 1.8V VCC, 1.2V VIO | 64Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
200(x1 x8), 200(x8 DTR) |
ECC,DTR, H/W RESET,WP#, Secured OTP |
TFBGA24 8x6mm (5x5 ball array), WLCSP (4x6 ball array) |
| GD55T02GE | MP | 3V | 2Gb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x4), 200(x4 DTR) |
ECC,DTR,Default 4I/O, H/W RESET, WP# | TFBGA24 8x6mm (5x5 ball array) |
| GD55F02GF | MP | 3V | 2Gb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x2 x4) 104(x2 x4 DTR) |
PASSWORD,CRC, ECC,DTR,Default 4I/O, H/W RESET, WP#, Secured OTP, Suspend, Unique ID | TFBGA24 8x6mm (5x5 ball array) |
| GD55B02GF | MP | 3V | 2Gb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
Default 4I/O, H/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP16 300mil, TFBGA24 8x6mm (5x5 ball array) |
| GD55B02GE | NR | 3V | 2Gb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
133(x1 x4), 90(x4 DTR) |
DTR,Default 4I/O, H/W RESET,WP#, Secured OTP | TFBGA24 8x6mm (5x5 ball array) |
| GD55LT02GE | MP | 1.8V | 2Gb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x4), 200(x4 DTR) |
ECC,DTR,Default 4I/O, H/W RESET, WP# | TFBGA24 8x6mm (5x5 ball array) |
| GD55LB02GE | NR | 1.8V | 2Gb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x4), 90(x4 DTR) |
DTR,Default 4I/O, H/W RESET,WP#, Secured OTP | TFBGA24 8x6mm (5x5 ball array) |
| GD55LB02GF | MP | 1.8V | 2Gb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
Default 4I/O, H/W RESET,WP#, Secured OTP |
SOP16 300mil, TFBGA24 8x6mm (5x5 ball array) |
| GD55T01GE | MP | 3V | 1Gb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x4), 200(x4 DTR) |
ECC,DTR,Default 4I/O, H/W RESET, WP# |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD55F01GF | MP | 3V | 1Gb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x2 x4) 104(x2 x4 DTR) |
PASSWORD,CRC, ECC,DTR,Default 4I/O, H/W RESET, WP#, Secured OTP, Suspend, Unique ID |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD55B01GF | MP | 3V | 1Gb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
Default 4I/O, H/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD55B01GE | NR | 3V | 1Gb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
133(x1 x4), 90(x4 DTR) |
DTR,Default 4I/O, H/W RESET,WP#, Secured OTP |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD55LT01GE | MP | 1.8V | 1Gb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x4), 200(x4 DTR) |
ECC,DTR,Default 4I/O, H/W RESET, WP# |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD55LB01GE | NR | 1.8V | 1Gb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x4), 90(x4 DTR) |
DTR,Default 4I/O, H/W RESET,WP#, Secured OTP |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD55LB01GF | MP | 1.8V | 1Gb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
Default 4I/O, H/W RESET,WP#, Secured OTP |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD55LR01GF | MP | 1.8V | 1Gb | -40℃~85℃ | 104(x1 x2 x4) |
RPMC,Default 4I/O, H/W RESET, WP# |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD25B512MF | MP | 3V | 512Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
Default 4I/O, H/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD25B512ME | NR | 3V | 512Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
133(x1 x4), 90(x4 DTR) |
DTR,Default 4I/O, H/W RESET,WP#, Secured OTP |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD25T512ME | MP | 3V | 512Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x4), 200(x4 DTR) |
ECC,DTR,Default 4I/O, H/W RESET, WP# |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD25F512MF | MP | 3V | 512Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x2 x4) 104(x2 x4 DTR) |
PASSWORD,CRC, ECC,DTR,Default 4I/O, H/W RESET, WP#, Secured OTP, Suspend, Unique ID |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD25R512MF | MP | 3V | 512Mb | -40℃~85℃ | 104(x1 x2 x4) |
RPMC,Default 4I/O, H/W RESET, WP# |
SOP16 300mil, WSON8 8x6mm |
| GD25R512ME | NR | 3V | 512Mb | -40℃~85℃ |
104(x1 x4), 60(x4 DTR) |
RPMC, DTR,Default 4I/O, H/W RESET, WP# |
SOP16 300mil, WSON8 8x6mm |
| GD55LT512WE | MP | 1.8V | 512Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x4), 200(x4 DTR) |
ECC,DTR,Default 4I/O, H/W RESET,WP#, RWW |
SOP16 300mil, TFBGA24 8x6mm (5x5 ball array) |
| GD25LB512ME | NR | 1.8V | 512Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x4), 90(x4 DTR) |
DTR,Default 4I/O, H/W RESET,WP#, Secured OTP |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array), WLCSP (3-2-3 ball array), |
| GD25LB512MF | MP | 1.8V | 512Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
Default 4I/O, H/W RESET,WP#, Secured OTP |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD25LT512ME | MP | 1.8V | 512Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x4), 200(x4 DTR) |
ECC,DTR,Default 4I/O, H/W RESET, WP# |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD25LR512ME | NR | 1.8V | 512Mb | -40℃~85℃ |
104(x1 x4), 60(x4 DTR) |
RPMC, DTR,Default 4I/O, H/W RESET, WP# |
SOP16 300mil, WSON8 8x6mm |
| GD25LR512MF | MP | 1.8V | 512Mb | -40℃~85℃ | 104(x1 x2 x4) |
RPMC,Default 4I/O, H/W RESET, WP# |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD25LF512MF | MP | 1.8V | 512Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x2 x4) 104(x2 x4 DTR) |
PASSWORD,CRC, ECC,DTR,Default 4I/O, H/W RESET, WP#, Secured OTP, Suspend, Unique ID |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD55LF01GF | MP | 1.8V | 1Gb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x2 x4) 104(x2 x4 DTR) |
PASSWORD,CRC, ECC,DTR,Default 4I/O, H/W RESET, WP#, Secured OTP, Suspend, Unique ID |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD55LF02GF | MP | 1.8V | 2Gb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x2 x4) 104(x2 x4 DTR) |
PASSWORD,CRC, ECC,DTR,Default 4I/O, H/W RESET, WP#, Secured OTP, Suspend, Unique ID | TFBGA24 8x6mm (5x5 ball array) |
| GD25NF512MF | MP | 1.8V VCC, 1.2V VIO | 512Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x2 x4) 104(x2 x4 DTR) |
1.2V VIO, PASSWORD,CRC, ECC,DTR,Default 4I/O, H/W RESET, WP#, Secured OTP, Suspend, Unique ID |
SOP16 300mil TFBGA24 8x6mm (5x5 ball array) |
| GD25LB256F | MP | 1.8V | 256Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
Default 4I/O, H/W RESET,WP#, Secured OTP |
WSON8 6x5mm, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD25LB256E | NR | 1.8V | 256Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x4), 104(x4 DTR) |
DTR,Default 4I/O, H/W RESET,WP#, Secured OTP |
WSON8 6x5mm, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array), WLCSP (4-4 ball array), WLCSP (3-2-3 ball array) |
| GD25LT256E | MP | 1.8V | 256Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x4), 200(x4 DTR) |
ECC,DTR,Default 4I/O, H/W RESET, WP# |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD25LR256F | MP | 1.8V | 256Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 104(x1 x2 x4) |
RPMC,Default 4I/O, H/W RESET, WP# |
SOP16 300mil WSON8 6x5mm WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD25LR256E | NR | 1.8V | 256Mb | -40℃~85℃ |
104(x1 x4), 60(x4 DTR) |
RPMC, DTR,Default 4I/O, H/W RESET, WP# |
SOP16 300mil, WSON8 6x5mm, WSON8 8x6mm |
| GD25LF256F | MP | 1.8V | 256Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x2 x4) 104(x2 x4 DTR) |
PASSWORD,CRC, ECC,DTR,Default 4I/O, H/W RESET, WP#, Secured OTP, Suspend, Unique ID |
SOP16 300mil WSON8 6x5mm WSON8 8x6mm TFBGA24 8x6mm (5x5 ball array) |
| GD25S512MD | NR | 3V | 512Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 104(x1 x2 x4) |
Default 4I/O, H/W RESET, Secured OTP, Suspend, Unique ID |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD25R256E | MP | 3V | 256Mb | -40℃~85℃ | 104(x1 x2 x4) |
RPMC, Default 4I/O, H/W RESET, Secured OTP, Suspend |
SOP16 300mil, WSON8 6x5mm, WSON8 8x6mm |
| GD25R256D | NR | 3V | 256Mb | -40℃~85℃ | 104(x1 x2 x4) |
RPMC, Default 4I/O, H/W RESET, Secured OTP, Suspend |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD25Q257D | NR | 3V | 256Mb |
-40℃~105℃, -40℃~125℃ |
104(x1 x2 x4), 80(x4 DTR) |
ECC,DTR, H/W RESET,WP#, Secured OTP |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD25Q256E | MP | 3V | 256Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
H/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP16 300mil, WSON8 6x5mm, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array), |
| GD25Q256D | NR | 3V | 256Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 104(x1 x2 x4) |
H/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD25F256F | MP | 3V | 256Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x2 x4), 104(x4 DTR) |
ECC,DTR,Default 4I/O, H/W RESET, Secured OTP |
SOP16 300mil, WSON8 6x5mm, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array), |
| GD25B257D | NR | 3V | 256Mb | -40℃~85℃ |
104(x1 x2 x4), 80(x4 DTR) |
ECC,DTR,Default 4I/O, H/W RESET, Secured OTP |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD25B256E | MP | 3V | 256Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
Default 4I/O, H/W RESET, Secured OTP, Suspend, Unique ID |
SOP16 300mil, WSON8 6x5mm, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array), |
| GD25B256D | NR | 3V | 256Mb | -40℃~85℃ | 104(x1 x2 x4) |
Default 4I/O, H/W RESET, Secured OTP, Suspend, Unique ID |
SOP16 300mil, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD25LQ256D | NR | 1.8V | 256Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 120(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP16 300mil, WSON8 6x5mm, WSON8 8x6mm |
| GD25LQ255E | MP | 1.8V | 256Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
H/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP16 300mil, WSON8 6x5mm, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array), WLCSP (4-4 ball array) |
| GD25LQ256H | MP | 1.8V | 256Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
133(x1 x2 x4) 104(x4 DTR) |
DTR,H/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 208mil, WSON8 6x5mm, WSON8 8x6mm |
| GD25LF255E | MP | 1.8V | 256Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x2 x4), 104(x4 DTR) |
DTR,Default 4I/O, H/W RESET, Secured OTP, Suspend |
WSON8 6x5mm, WLCSP (4-4 ball array) |
| GD25LE256D | NR | 1.8V | 256Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 120(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP16 300mil, WSON8 6x5mm, WSON8 8x6mm |
| GD25LE255E | MP | 1.8V | 256Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
H/W RESET,WP#, Secured OTP, Suspend, Unique ID |
WSON8 6x5mm, WLCSP (4-4 ball array) |
| GD25LE256H | MP | 1.8V | 256Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x2 x4) 104(x4 DTR) |
DTR,H/W RESET,WP#, Secured OTP, Suspend, Unique ID |
WSON8 6x5mm, WLCSP (4-4 ball array) |
| GD25LB256D | NR | 1.8V | 256Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 120(x1 x2 x4) |
Default 4I/O, S/W RESET, Secured OTP, Suspend, Unique ID |
SOP16 300mil, WSON8 6x5mm, WSON8 8x6mm |
| GD25WB256E | MP | 1.65V~3.6V | 256Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 104(x1 x2 x4) |
Default 4I/O, H/W RESET, Secured OTP, Suspend, Unique ID |
SOP16 300mil, WSON8 6x5mm, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array), |
| GD25NF256F | MP | 1.8V VCC, 1.2V VIO | 256Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x2 x4) 104(x2 x4 DTR) |
1.2V VIO, PASSWORD,CRC, ECC,DTR,Default 4I/O, H/W RESET, WP#, Secured OTP, Suspend, Unique ID |
SOP16 300mil TFBGA24 8x6mm (5x5 ball array) |
| GD25NE256H | UD | 1.8V VCC, 1.2V VIO | 256Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
133(x1 x2 x4) 104(x4 DTR) |
1.2V VIO, DTR, H/W RESET, Secured OTP, Suspend, Unique ID |
SOP16 300mil TFBGA24 8x6mm (5x5 ball array) |
| GD25UF256E | UD | 1.2V | 256Mb |
-40℃~85℃ -40℃~105℃ -40℃~125℃ |
120(x1 x2 x4), 80(x4 DTR) |
DTR,Default 4I/O, H/W RESET,WP#, Secured OTP |
WSON8 6x5mm, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array), SOP16 300mil, SOP8 208mil |
| GD25R128E | MP | 3V | 128Mb | -40℃~85℃ | 104(x1 x2 x4) |
RPMC, Default 4I/O, H/W RESET, Secured OTP, Suspend |
SOP8 208mil, WSON8 6x5mm, WSON8 8x6mm |
| GD25R127D | NR | 3V | 128Mb | -40℃~85℃ | 104(x1 x2 x4) |
RPMC, Default 4I/O, S/W RESET, Secured OTP, Suspend |
SOP8 208mil, SOP16 300mil, WSON8 6x5mm, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD25Q128H | MP | 3V | 128Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
133(x1 x2 x4), 80(x4 DTR) |
DTR,H/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x4mm, USON8 4x4mm, WSON8 6x5mm |
| GD25Q128E | MP | 3V | 128Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
H/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 208mil, SOP16 300mil, USON8 4x4mm, WSON8 6x5mm, WSON8 8x6mm |
| GD25Q127C | NR | 3V | 128Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 104(x1 x2 x4) |
H/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 208mil, SOP16 300mil, WSON8 6x5mm, WSON8 8x6mm, |
| GD25F128F | MP | 3V | 128Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x2 x4), 104(x4 DTR) |
ECC,DTR,Default 4I/O, H/W RESET, Secured OTP |
SOP8 208mil, SOP16 300mil, WSON8 6x5mm, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD25B128H | MP | 3V | 128Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
133(x1 x2 x4), 80(x4 DTR) |
DTR,WP#, Default 4I/O, S/W RESET, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x4mm, USON8 4x4mm, WSON8 6x5mm |
| GD25B128E | MP | 3V | 128Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
Default 4I/O, H/W RESET, Secured OTP, Suspend, Unique ID |
SOP8 208mil, USON8 4x4mm, WSON8 6x5mm, WSON8 8x6mm, |
| GD25B127D | NR | 3V | 128Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 104(x1 x2 x4) |
Default 4I/O, S/W RESET, Secured OTP, Suspend, Unique ID |
SOP8 208mil, WSON8 6x5mm, WSON8 8x6mm |
| GD25LR128E | MP | 1.8V | 128Mb |
-40℃~85℃, -40℃~105℃ | 104(x1 x2 x4) |
RPMC, Default 4I/O, S/W RESET, Secured OTP, Suspend |
SOP8 208mil, WSON8 6x5mm, WSON8 8x6mm |
| GD25LR128D | NR | 1.8V | 128Mb | -40℃~85℃ | 120(x1 x2 x4) |
RPMC, Default 4I/O, S/W RESET, Secured OTP, Suspend |
SOP8 208mil, WSON8 6x5mm, WSON8 8x6mm |
| GD25LQ128E | MP | 1.8V | 128Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
H/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 208mil, USON8 4x4mm, WSON8 6x5mm, WSON8 8x6mm, WLCSP (4-4 ball array) |
| GD25LQ128D | NR | 1.8V | 128Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 120(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 208mil, VSOP8 208mil, WSON8 6x5mm |
| GD25LQ128H | UD | 1.8V | 128Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
133(x1 x2 x4), 104(x2 x4 DTR) |
H/W RESET, WP#, Security Registers with OTP Locks, Suspend, Unique ID, HOLD# |
SOP8 150mil, SOP8 208mil, SOP16 300mil, USON8 4x4mm, WSON8 6x5mm |
| GD25LF128E | NR | 1.8V | 128Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x2 x4), 104(x4 DTR) |
DTR,Default 4I/O, H/W RESET, Secured OTP, Suspend |
SOP8 208mil, USON8 4x4mm, WSON8 6x5mm |
| GD25LF128J | MP | 1.8V | 128Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x2 x4), 104(x2 x4 DTR) |
ECC,DTR,Default 4I/O, H/W RESET, Secured OTP, Suspend |
SOP8 208mil, USON8 4x4mm, WSON8 6x5mm, WSON8 8x6mm, TFBGA24 8x6mm (5x5 ball array) |
| GD25LE128E | MP | 1.8V | 128Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
133(x1 x2 x4), 104(x4 DTR) |
H/W RESET,WP#, Secured OTP, Suspend, Unique ID |
FO-USON8 3x3mm, USON8 4x4mm, WSON8 6x5mm, VSOP8 208mil, WLCSP (4-4 ball array) |
| GD25LE128D | NR | 1.8V | 128Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 120(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 208mil, VSOP8 208mil, WSON8 6x5mm, WSON8 8x6mm, WLCSP (4-4 ball array) |
| GD25LE128H | UD | 1.8V | 128Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x2 x4), 104(x2 x4 DTR) |
H/W RESET, WP#, Security Registers with OTP Locks, Suspend, Unique ID, HOLD# |
SOP8 150mil, SOP8 208mil, USON8 4x4mm, WSON8 6x5mm |
| GD25LB128E | MP | 1.8V | 128Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
Default 4I/O, H/W RESET, Secured OTP, Suspend, Unique ID |
SOP8 208mil, USON8 4x4mm, WSON8 6x5mm, WSON8 8x6mm, |
| GD25LB128D | NR | 1.8V | 128Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 120(x1 x2 x4) |
Default 4I/O, S/W RESET, Secured OTP, Suspend, Unique ID |
SOP8 208mil, VSOP8 208mil, WSON8 6x5mm, WLCSP (4-4 ball array), |
| GD25WQ128H | MP | 1.65V~3.6V | 128Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
104(x1 x2 x4), 66(x4 DTR) |
H/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x4mm, USON8 4x4mm, WSON8 6x5mm |
| GD25WQ128E | MP | 1.65V~3.6V | 128Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 104(x1 x2 x4) |
H/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 208mil, USON8 4x4mm, WSON8 6x5mm, WSON8 8x6mm, |
| GD25NE128H | UD | 1.8V VCC, 1.2V VIO | 128Mb | -40℃~85℃ |
133(x1 x2 x4), 104(x2 x4 DTR) |
1.2V VIO, DTR, H/W RESET, Security Registers with OTP Locks, Suspend, Unique ID |
SOP16 300mil, TFBGA24 8x6mm (5x5 ball array) |
| GD25UF128E | MP | 1.2V | 128Mb |
-40℃~85℃ -40℃~105℃ -40℃~125℃ |
120(x1 x2 x4), 80(x4 DTR) |
DTR,Default 4I/O, H/W RESET,WP#, Secured OTP |
SOP8 208mil, USON8 4x4mm, WSON8 6x5mm, TFBGA24 8x6mm (5x5 ball array), WLCSP (4-4 ball array) |
| GD25R64E | MP | 3V | 64Mb | -40℃~85℃ | 104(x1 x2 x4) |
RPMC, Default 4I/O, S/W RESET, Secured OTP, Suspend |
SOP8 208mil, WSON8 6x5mm, WSON8 8x6mm |
| GD25Q64H | MP | 3V | 64Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
133(x1 x2 x4), 80(x4 DTR) |
DTR,H/W RESET,WP#, Secured OTP, Suspend, Unique ID |
FO-USON8 3x2mm, SOP8 150mil, SOP8 208mil, USON8 3x4mm, USON8 4x4mm |
| GD25Q64E | MP | 3V | 64Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x4mm, USON8 4x4mm, WSON8 6x5mm |
| GD25Q64C | NR | 3V | 64Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 120(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 208mil, USON8 4x4mm, WSON8 6x5mm |
| GD25F64F | MP | 3V | 64Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x2 x4), 104(x4 DTR) |
ECC,DTR,Default 4I/O, H/W RESET, Secured OTP |
SOP8 208mil, USON8 4x4mm, WSON8 6x5mm |
| GD25B64H | MP | 3V | 64Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
133(x1 x2 x4), 80(x4 DTR) |
DTR,WP#, Default 4I/O, S/W RESET, Secured OTP, Suspend, Unique ID |
FO-USON8 3x2mm, SOP8 150mil, SOP8 208mil, USON8 3x4mm |
| GD25B64E | MP | 3V | 64Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
Default 4I/O, S/W RESET, Secured OTP, Suspend, Unique ID |
SOP8 208mil, USON8 3x4mm, USON8 4x4mm, WSON8 6x5mm, |
| GD25B64C | NR | 3V | 64Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 120(x1 x2 x4) |
Default 4I/O, S/W RESET, Secured OTP, Suspend, Unique ID |
SOP8 208mil, SOP16 300mil, WSON8 6x5mm, WSON8 8x6mm, |
| GD25LR64E | MP | 1.8V | 64Mb |
-40℃~85℃, -40℃~105℃ | 104(x1 x2 x4) |
RPMC, Default 4I/O, S/W RESET, Secured OTP, Suspend |
SOP8 208mil, WSON8 6x5mm |
| GD25LQ64E | MP | 1.8V | 64Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 208mil, USON8 3x4mm, USON8 4x4mm, WSON8 6x5mm, WLCSP (4-4 ball array) |
| GD25LF64E | NR | 1.8V | 64Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x2 x4), 104(x4 DTR) |
DTR,Default 4I/O, S/W RESET, Secured OTP, Suspend |
SOP8 150mil, SOP8 208mil, USON8 3x4mm, WSON8 6x5mm, |
| GD25LE64E | MP | 1.8V | 64Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
133(x1 x2 x4), 104(x4 DTR) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 208mil, USON8 3x4mm, FO-USON8 (3x2mm), USON8 4x4mm, WLCSP (4-4 ball array) |
| GD25LB64E | MP | 1.8V | 64Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
Default 4I/O, S/W RESET, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x4mm, USON8 4x4mm, WSON8 6x5mm |
| GD25UF64E | MP | 1.2V | 64Mb |
-40℃~85℃ -40℃~105℃ -40℃~125℃ |
120(x1 x2 x4), 80(x4 DTR) |
DTR,Default 4I/O, H/W RESET,WP#, Secured OTP |
SOP8 208mil, USON8 3x4mm, WLCSP (4-4 ball array) |
| GD25WQ64E | MP | 1.65V~3.6V | 64Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 104(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 208mil, USON8 3x4mm, USON8 4x4mm, WSON8 6x5mm, WLCSP (3-2-3 ball array) |
| GD25WQ64H | MP | 1.65V~3.6V | 64Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
104(x1 x2 x4), 66(x4 DTR) |
H/W RESET,WP#, Secured OTP, Suspend, Unique ID |
FO-USON8 (3x2mm), SOP8 150mil, SOP8 208mil, USON8 3x4mm, USON8 4x4mm, WSON8 6x5mm, WLCSP (4-4 ball array) |
| GD25Q32E | MP | 3V | 32Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x2mm, USON8 3x4mm, WSON8 6x5mm |
| GD25Q32C | NR | 3V | 32Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 120(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x4mm, WSON8 6x5mm, |
| GD25B32E | MP | 3V | 32Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
Default 4I/O, S/W RESET, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x2mm, USON8 3x4mm, WSON8 6x5mm |
| GD25B32C | NR | 3V | 32Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 120(x1 x2 x4) |
Default 4I/O, S/W RESET, Secured OTP, Suspend, Unique ID |
SOP8 208mil, DIP8 300mil, WSON8 6x5mm |
| GD25LR32E | MP | 1.8V | 32Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 104(x1 x2 x4) |
RPMC, Default 4I/O, S/W RESET, Secured OTP, Suspend |
SOP8 150mil, SOP8 208mil, WSON8 6x5mm |
| GD25LQ32E | MP | 1.8V | 32Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 208mil, USON8 3x2mm, USON8 3x4mm, WLCSP (4-4 ball array), WLCSP (3-2-3 ball array) |
| GD25LQ32D | NR | 1.8V | 32Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 120(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 208mil, USON8 3x4mm, WLCSP (4-4 ball array) |
| GD25LF32E | NR | 1.8V | 32Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x2 x4), 104(x4 DTR) |
DTR,Default 4I/O, S/W RESET, Secured OTP, Suspend |
SOP8 150mil, SOP8 208mil, USON8 3x2mm, USON8 3x4mm, WSON8 6x5mm |
| GD25LE32E | MP | 1.8V | 32Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
133(x1 x2 x4), 104(x4 DTR) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
USON8 3x2mm, USON8 3x4mm, USON8 4x4mm, WLCSP (4-4 ball array), WLCSP (3-2-3 ball array) |
| GD25LE32D | NR | 1.8V | 32Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 120(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
USON8 3x4mm, USON8 4x4mm, WLCSP (4-4 ball array) |
| GD25LB32E | MP | 1.8V | 32Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
Default 4I/O, S/W RESET, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x4mm, USON8 4x4mm, WSON8 6x5mm |
| GD25LB32D | NR | 1.8V | 32Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 120(x1 x2 x4) |
Default 4I/O, S/W RESET, Secured OTP, Suspend, Unique ID |
SOP8 208mil, USON8 3x4mm, USON8 4x4mm, WSON8 6x5mm, |
| GD25UF32E | S | 1.2V | 32Mb |
-40℃~85℃ -40℃~105℃ -40℃~125℃ |
104(x1 x2 x4), 60(x4 DTR) |
DTR,Default 4I/O, H/W RESET,WP#, Secured OTP |
SOP8 150mil, SOP8 208mil, USON8 3x2mm, USON8 3x4mm, WLCSP (3-2-3 ball array) |
| GD25WQ32E | MP | 1.65V~3.6V | 32Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 104(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x2mm, USON8 3x4mm, |
| GD25Q16E | MP | 3V | 16Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x2mm, USON8 3x4mm |
| GD25Q16C | NR | 3V | 16Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 120(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x2mm, USON8 3x4mm |
| GD25Q16M | UD | 3V | 16Mb | -40℃~85℃ |
133(x1 x2 x4), 104(x4 DTR) |
S/W RESET, WP#, Security Registers with OTP Locks, Suspend, Unique ID, HOLD# |
SOP8 150mil, SOP8 208mil, USON8 3x2mm, USON8 3x4mm, USON8 4x4mm, USON8 1.5x1.5mm |
| GD25B16E | MP | 3V | 16Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
Default 4I/O, S/W RESET, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x2mm, USON8 3x4mm |
| GD25B16C | NR | 3V | 16Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 120(x1 x2 x4) |
Default 4I/O, S/W RESET, Secured OTP, Suspend, Unique ID |
SOP8 208mil, WSON8 6x5mm |
| GD25LQ16E | MP | 1.8V | 16Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x2mm, USON8 3x4mm, WLCSP (3-2-3 ball array) |
| GD25LQ16C | NR | 1.8V | 16Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 104(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x4mm |
| GD25LF16E | NR | 1.8V | 16Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x2 x4), 104(x4 DTR) |
DTR,Default 4I/O, S/W RESET, Secured OTP, Suspend |
SOP8 150mil, SOP8 208mil, USON8 3x2mm, USON8 3x4mm, |
| GD25LE16E | MP | 1.8V | 16Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
133(x1 x2 x4), 104(x4 DTR) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 208mil, USON8 3x2mm, WLCSP (3-2-3 ball array) |
| GD25LE16C | NR | 1.8V | 16Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 104(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID | SOP8 208mil |
| GD25LB16E | MP | 1.8V | 16Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
Default 4I/O, S/W RESET, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x2mm, USON8 3x4mm, WSON8 6x5mm |
| GD25LB16C | NR | 1.8V | 16Mb | -40℃~85℃ | 104(x1 x2 x4) |
Default 4I/O, S/W RESET, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x4mm, WSON8 6x5mm, |
| GD25UF16E | S | 1.2V | 16Mb |
-40℃~85℃ -40℃~105℃ -40℃~125℃ |
104(x1 x2 x4), 60(x4 DTR) |
DTR,Default 4I/O, H/W RESET,WP#, Secured OTP |
SOP8 150mil, SOP8 208mil, USON8 3x2mm, USON8 3x4mm, WLCSP (3-2-3 ball array) |
| GD25WQ16E | MP | 1.65V~3.6V | 16Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 104(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x2mm |
| GD25Q80E | MP | 3V | 8Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x2mm, USON8 3x4mm, WSON8 6x5mm |
| GD25Q80C | NR | 3V | 8Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 120(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x2mm, USON8 3x4mm, WSON8 6x5mm |
| GD25LQ80E | MP | 1.8V | 8Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x2mm, WSON8 6x5mm, |
| GD25LQ80C | NR | 1.8V | 8Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 104(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x2mm, WSON8 6x5mm, |
| GD25LF80E | NR | 1.8V | 8Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
166(x1 x2 x4), 104(x4 DTR) |
DTR,Default 4I/O, S/W RESET, Secured OTP, Suspend |
SOP8 208mil, USON8 3x2mm, USON8 3x4mm |
| GD25LE80E | MP | 1.8V | 8Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
133(x1 x2 x4), 104(x4 DTR) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, USON8 3x2mm, WLCSP (4-4 ball array) |
| GD25LE80C | NR | 1.8V | 8Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 104(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, USON8 3x2mm, WLCSP (4-4 ball array) |
| GD25WQ80E | MP | 1.65V~3.6V | 8Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 104(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x2mm, WSON8 6x5mm, |
| GD25UF80E | S | 1.2V | 8Mb |
-40℃~85℃ -40℃~105℃ -40℃~125℃ |
104(x1 x2 x4), 60(x4 DTR) |
DTR,Default 4I/O, H/W RESET,WP#, Secured OTP |
SOP8 150mil, SOP8 208mil, USON8 3x2mm, WLCSP (4-4 ball array) |
| GD25Q40E | MP | 3V | 4Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 1.5x1.5mm, USON8 3x2mm |
| GD25Q40C | NR | 3V | 4Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 120(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x2mm |
| GD25B40C | NR | 3V | 4Mb | -40℃~85℃ | 120(x1 x2 x4) |
Default 4I/O, S/W RESET, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x2mm |
| GD25LQ40E | MP | 1.8V | 4Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, USON8 1.5x1.5mm, USON8 3x2mm |
| GD25LQ40C | NR | 1.8V | 4Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 104(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x2mm, USON8 3x4mm, |
| GD25LE40E | MP | 1.8V | 4Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil USON8 1.5x1.5mm USON8 3x2mm |
| GD25LE40C | NR | 1.8V | 4Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 104(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, USON8 3x2mm, USON8 3x4mm |
| GD25WQ40E | MP | 1.65V~3.6V | 4Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 104(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, WLCSP (4x6 ball array), USON8 1.5x1.5mm, USON8 3x2mm |
| GD25Q20E | MP | 3V | 2Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208milUSON8 3x2mm, |
| GD25Q20C | NR | 3V | 2Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 120(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x2mm |
| GD25LQ20E | MP | 1.8V | 2Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, USON8 1.5x1.5mm, USON8 3x2mm |
| GD25LQ20C | NR | 1.8V | 2Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 104(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, SOP8 208mil, USON8 3x2mm, USON8 3x4mm, |
| GD25LE20E | MP | 1.8V | 2Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 133(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, USON8 1.5x1.5mm, USON8 3x2mm |
| GD25LE20C | NR | 1.8V | 2Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 104(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, USON8 3x2mm, USON8 3x4mm |
| GD25WQ20E | MP | 1.65V~3.6V | 2Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ | 104(x1 x2 x4) |
S/W RESET,WP#, Secured OTP, Suspend, Unique ID |
SOP8 150mil, USON8 3x2mm, USON8 1.5x1.5mm, WLCSP (2x3 ball array) |
| GD25D80E | MP | 3V | 8Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
104(x1), 80(x2) |
WP#,Secured OTP, Unique ID |
SOP8 150mil, USON8 1.5x1.5mm, USON8 3x2mm |
| GD25LD80E | MP | 1.8V | 8Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
50(x1), 40(x2) |
WP#,Secured OTP, Unique ID |
SOP8 150milUSON8 1.5x1.5mm, USON8 3x2mm |
| GD25WD80E | MP | 1.65V~3.6V | 8Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
104(x1), 80(x2) |
WP#,Secured OTP, Unique ID |
SOP8 150milUSON8 1.5x1.5mm, USON8 3x2mm, SOP8 208mil |
| GD25D40E | MP | 3V | 4Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
104(x1), 80(x2) |
WP#,Secured OTP, Unique ID |
SOP8 150mil, USON8 1.5x1.5mm, USON8 3x2mm, USON6 1.2x1.2mm |
| GD25D40C | NR | 3V | 4Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
104(x1), 80(x2) | WP#,Unique ID |
SOP8 150mil, SOP8 208mil, USON8 1.5x1.5mm, USON8 3x2mm |
| GD25LD40C | NR | 1.8V | 4Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
50(x1), 40(x2) | WP#,Unique ID |
SOP8 150mil, SOP8 208mil, USON8 1.5x1.5mm, USON8 3x2mm, WSON8 6x5mm |
| GD25LD40E | MP | 1.8V | 4Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
50(x1), 40(x2) |
WP#,Secured OTP, Unique ID |
SOP8 150mil, USON8 1.5x1.5mm, USON8 3x2mm |
| GD25WD40E | MP | 1.65V~3.6V | 4Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
104(x1), 80(x2) |
WP#,Secured OTP, Unique ID |
SOP8 150mil, USON8 1.5x1.5mm, USON8 3x2mm, USON6 1.2x1.2mm |
| GD25WD40C | NR | 1.65V~3.6V | 4Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
100(x1), 80(x2) | WP#,Unique ID |
SOP8 150mil, USON8 1.5x1.5mm, USON8 3x2mm, WLCSP (4-4 ball array) |
| GD25D20E | MP | 3V | 2Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
104(x1), 80(x2) |
WP#,Secured OTP, Unique ID |
SOP8 150mil, USON8 1.5x1.5mm, USON8 3x2mm, USON6 1.2x1.2mm |
| GD25D20C | NR | 3V | 2Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
104(x1), 80(x2) | WP#,Unique ID |
SOP8 150mil, SOP8 208mil, USON8 1.5x1.5mm, USON8 3x2mm |
| GD25LD20C | NR | 1.8V | 2Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
50(x1), 40(x2) | WP#,Unique ID |
SOP8 150mil, SOP8 208mil, USON8 1.5x1.5mm, USON8 3x2mm |
| GD25LD20E | MP | 1.8V | 2Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
50(x1), 40(x2) |
WP#,Secured OTP, Unique ID |
SOP8 150mil, USON8 1.5x1.5mm, USON8 3x2mm |
| GD25WD20E | MP | 1.65V~3.6V | 2Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
104(x1), 80(x2) |
WP#,Secured OTP, Unique ID |
SOP8 150mil, USON8 1.5x1.5mm, USON8 3x2mm, USON6 1.2x1.2mm |
| GD25WD20C | NR | 1.65V~3.6V | 2Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
100(x1), 80(x2) | WP#,Unique ID |
SOP8 150mil, USON8 1.5x1.5mm, USON8 3x2mm, WLCSP (4-4 ball array) |
| GD25D10E | MP | 3V | 1Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
104(x1), 80(x2) | WP#,Unique ID |
SOP8 150mil, USON8 1.5x1.5mm, USON8 3x2mm, USON6 1.2x1.2mm |
| GD25D10C | NR | 3V | 1Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
100(x1), 80(x2) | WP#,Unique ID |
SOP8 150mil, SOP8 208mil, USON8 1.5x1.5mm, USON8 3x2mm |
| GD25LD10E | MP | 1.8V | 1Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
50(x1), 40(x2) | WP#,Unique ID |
SOP8 150mil, USON8 3x2mm, USON8 1.5x1.5mm, USON6 1.2x1.2mm |
| GD25LD10C | NR | 1.8V | 1Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
50(x1), 40(x2) | WP#,Unique ID |
SOP8 150mil, SOP8 208mil, USON8 1.5x1.5mm, USON8 3x2mm, |
| GD25WD10E | MP | 1.65V~3.6V | 1Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
104(x1), 80(x2) | WP#,Unique ID |
SOP8 150mil, USON8 1.5x1.5mm, USON8 3x2mm, USON6 1.2x1.2mm |
| GD25WD10C | NR | 1.65V~3.6V | 1Mb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
100(x1), 80(x2) | WP#,Unique ID |
SOP8 150mil, USON8 1.5x1.5mm, USON8 3x2mm, USON6 1.2x1.2mm |
| GD25D05E | MP | 3V | 512Kb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
104(x1), 80(x2) | WP#,Unique ID |
SOP8 150mil, USON8 1.5x1.5mm, USON8 3x2mm, USON6 1.2x1.2mm |
| GD25D05C | NR | 3V | 512Kb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
100(x1), 80(x2) | WP#,Unique ID |
SOP8 150mil, SOP8 208mil, USON8 1.5x1.5mm, USON8 3x2mm |
| GD25LD05E | MP | 1.8V | 512Kb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
50(x1), 40(x2) | WP#,Unique ID |
SOP8 150mil, USON8 3x2mm, USON8 1.5x1.5mm, USON6 1.2x1.2mm |
| GD25LD05C | NR | 1.8V | 512Kb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
50(x1), 40(x2) | WP#,Unique ID |
SOP8 150mil, SOP8 208mil, USON8 1.5x1.5mm, USON8 3x2mm |
| GD25WD05E | MP | 1.65V~3.6V | 512kb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
104(x1), 80(x2) | WP#,Unique ID |
SOP8 150mil, USON8 1.5x1.5mm, USON8 3x2mm, USON6 1.2x1.2mm |
| GD25WD05C | NR | 1.65V~3.6V | 512Kb |
-40℃~85℃, -40℃~105℃, -40℃~125℃ |
100(x1), 80(x2) | WP#,Unique ID |
SOP8 150mil, SOP8 208mil, USON8 1.5x1.5mm, USON8 3x2mm, USON6 1.2x1.2mm |
重点产品推荐
